Bitumen
Asphalt , also known as bitumen is a sticky, black and highly viscous liquid or semi-solid form of petroleum. It may be found in natural deposits or may be a refined product; it is a substance classed as a pitch. The primary use (70%) of asphalt/bitumen is in road construction, where it is used as the glue or binder mixed with aggregate particles to create asphalt concrete. Its other main uses are for bituminous waterproofing products, including production of roofing felt and for sealing flat roofs. Asphalt concrete pavement mixes are typically composed of 5% asphalt/bitumen cement and 95% aggregates (stone, sand, and gravel).
Bitumen
Properties | Unit | Bitumen 40/50 | Bitumen 60/70 | Bitumen 85/100 | Test Method |
Sp. Gr. @25/25°C | 1.01/1.06 | 1.01/1.06 | 1.00/1.05 | ASTM D 70 | |
Penetration @25°C | 40/50 | 60/70 | 85/100 | ASTM D 5762 | |
Softening Point | °C | 52/60 | 49/56 | 45/52 | ASTM D 36 |
Ductility @25°C | 100 min | 100 min | 100 min | ASTM D 113 | |
Loss on Heating | %Wt | 0.2 max | 0.2 max | 0.5 max | ASTM D 6 |
Drop in Penetration after Heating | % | 20 max | 20 max | 20 max | ASTM D 6 & ASTM D 5 |
Flash Point | °C | 250 min | 250 min | 225 min | ASTM D 92 |
Solubility in CS2 | %Wt | 99.5 min | 99.5 min | 99.5 min | ASTM D 4007 |
Spot Test | Negative | Negative | 0.2 max | AASHO T102 |
