Condensate, Raffinate and Cut Products

Condensate is a generic term that many use to describe a variety of light petroleum streams that range from NGLs to light crude oil. Strictly speaking, a condensate is a mixture of hydrocarbons that exists in a gaseous state in an underground gas reservoir but condenses under atmospheric conditions.

Raffinate is a product which has had a component or components removed. The product containing the removed materials is referred to as the extract. For example, in solvent extraction, the raffinate is the liquid stream which remains after solutes from the original liquid are removed through contact with an immiscible liquid. In metallurgy, raffinating refers to a process in which impurities are removed from liquid material.

C4-cut

Properties	Unit	Specification	Test Method
1,3-Butadiene	%Wt	47-53	AN-JG-NO.1
1 & I-Butene	%Wt	43 MAX	AN-JG-NO.1
N & I-Butane	%Wt	2.7 MAX	AN-JG-NO.1
Methyl Acetylene	%Wt	0.14 MAX	AN-JG-NO.1
Ethyl Acetylene	%Wt	0.55 MAX	AN-JG-NO.1
Vinyl Acetylene	%Wt	2.05 MAX	AN-JG-NO.1
1,2 – Butadiene	%Wt	0.5 MAX	AN-JG-NO.1
Trans- 2 – Butene	%Wt	3.5 MAX	AN-JG-NO.1
Cis -2- Butene	%Wt	4.5 MAX	AN-JG-NO.1
C-5	%Wt	0.3 MAX	AN-JG-NO.1

Download PDF

C6-cut

Properties	Unit	Specification	Test Method
Benzene	%WT	80 Min.	By GC
DN Value	gl²/100g	2 Max.	UOP 326

Download PDF

Butene-1

Properties	Unit	Specification
Purity	%Wt	99 Min
Carbon Monoxide	ppm (vol)	1 Max
Carbon Dioxide	ppm (vol)	2 Max
Ethane	ppm (vol)	600 Max
Ethylene	ppm (vol)	500 Max
Other Butenes or Butanes	ppm (vol)	10000 Max
C6 (Not Cyclic)	ppm (vol)	50 Max

Download PDF

Raffinate

Properties	Unit	Specification	Test Method
RVP	psia	Max 11	ASTM D 323
IBP	°C	Min 30	ASTM D 86
FBP	°C	Max 130	ASTM D 86
Paraffinic	%Wt	Min 70	GC
Olefin	%Wt	Max 14	GC
Density @15.6°C	kg/m³	650-740	ASTM D 4052
Total Sulfur	ppm (wt)	Max 1.5	ASTM D 5453
Color	Saybolt	Min +18	ASTM D 156
Lead	ppb (wt)	Max 5	GFAAS

Download PDF

Aromatic Raffinate

Properties	Unit	Specification	Test Method
Density @20°C	g/ml	0.84 Min	ASTM D 1298
IBP	°C	60 Min	ASTM D 86
FBP	°C	200 Max	ASTM D 86
Total Sulfur	ppm	500 Max	ASTM D 4294
Color		Clear & Light Yellow	Visual
Aromatic	%Wt	60 Min	GC
Benzene	%Wt	10 Max	GC
Toluene & Xylene	%Wt	45 Min	GC

Download PDF

Butane-Butene Raffinate (BBR)

Properties	Unit	Specification	Test Method
I-Butene	%Wt	65 Min	ASTM D 2426
1-Butene	%Wt	20 Max	ASTM D 2426
N & I Butane	%Wt	4.96 max	ASTM D 2426
C3 Cut	%Wt	0.23 Max	ASTM D 2426
Trans-2- Butene	%Wt	7.48 Max	ASTM D 2426
Cis-2-Butene	%Wt	3.03 Max	ASTM D 2426
1, 3 Butadiene	%Wt	0.3 Max	ASTM D 2426

Download PDF

Condensates

Properties	Unit	Specification	Test Method
Sp. Gr. 15.6/15.6 °C		0.7228	ASTM D 4052
API Gravity	°API	64.3	ASTM D 1298
Sulfur Content	%Wt	0.03	ASTM D 4294
Mercaptan Content	ppm	144	UOP 163
H₂S Content	ppm	<1	UOP 163
Water Content	ppm	104	ASTM D 4928
Nitrogen Content	ppm	<10	ASTM D 5762
Saturate Content	%Vol	91.2	ASTM D 1319
Olefin Content	%Vol	0.7	ASTM D 1319
Aromatic Content	%Vol	8.17	ASTM D 1319
Kinematic Viscosity @0°C	%Vol	0.8897	ASTM D 445
Kinematic Viscosity @10°C	mm²/s	0.7272	ASTM D 445
Kinematic Viscosity @20°C	mm²/s	0.6745	ASTM D 445
Pour Point	°C	<-39	ASTM D 97
RVP	psi	7.55	ASTM D 323
Cold Filter Plugging Point	°C	<-32	IP 309
Wax Content	%Wt	0.03	BP 237
Drop Melting Point of Wax	°C	<1	IP 133
Copper Corrosion, 3hrs @ 50°C		1b	ASTM D 130
Total Acidity	mgKOH/g	<1	ASTM D 664
Aniline Point	°C	57	ASTM D 611
Molecular Weight		138	Osmomat
Color	Saybolt	30	ASTM D 156
Lead Content	ppm	<1	ASTM D 5863
