Polymers

High-density polyethylene (HDPE) is a polyethylene thermoplastic made from petroleum. It is sometimes called “alkathene” or “polythene” when used for pipes. With a high strength-to-density ratio, HDPE is used in the production of plastic bottles, corrosion-resistant piping, geomembranes, and plastic lumber. HDPE is commonly recycled, and has the number “2” as its resin identification code.

Linear low-density polyethylene (LLDPE) is a substantially linear polymer, with significant numbers of short branches, commonly made by copolymerization of ethylene with longer-chain olefins. Linear low-density polyethylene differs structurally from conventional low-density polyethylene (LDPE) because of the absence of long chain branching. The linearity of LLDPE results from the different manufacturing processes of LLDPE and LDPE. In general, LLDPE is produced at lower temperatures and pressures by copolymerization of ethylene and such higher alpha-olefins as butene, hexene, or octene. The copolymerization process produces an LLDPE polymer that has a narrower molecular weight distribution than conventional LDPE and in combination with the linear structure, significantly different rheological properties.

Polypropylene (PP), also known as polypropene, is a thermoplastic polymer used in a wide variety of applications including packaging and labeling, textiles (e.g., ropes, thermal underwear and carpets), stationery, plastic parts and reusable containers of various types, laboratory equipment, loudspeakers, automotive components, and polymer banknotes. An addition polymer made from the monomer propylene, it is rugged and unusually resistant to many chemical solvents, bases and acids.

Extrusion- PIPE (Basell license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
AM 5010 T2 N (EX3)0.450.945PE-80 Pressure pipe, e.g. drinking water and gas pipes, waste pipes and sewer pipes, their fittings and also sheets (natural grade).
AM 5010 T2 B (EX3B)0.450.954PE-80 Pressure pipes, e.g. drinking water and gas pipes, waste pipes and sewer pipes, their fittings and also sheets (black grade)
AM 5010 T3 N0.430.944High quality PE-80 pressure pipe for gas and water transportation (natural grade).
AM 5010 T3 B0.430.954High quality PE-80 pressure pipe for gas and water transportation (black grade).
AM CRP 100 N (PE – 100 W)0.220.948Top quality PE-100 pressure pipes for gas and water transportation at higher pressures or with thinner walls as PE-80(natural grade).
AM CRP 100 B PE – 100 B0.220.957Leading PE-100 for pressure pipes for all purposes for gas, water and sewage transportation (black grade).
AM CRP 100 Blue
(PE – 100 Blue)
0.220.948Leading PE-100, specially for drinking water (blue marker)

Download PDF

Extrusion – Stretched Film and tape (Basell license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
AF 7740 F (EX 1)1.60.944Stretched films and tapes for production of high quality knitted and woven.
AF 7740 F2 (EX1 S)1.80.944Tapes to be used for agricultural packaging and as protective cover.

Download PDF

Extrusion – Tubular film (Basell license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
AM 9450 F  (EX5)0.280.949For blown films with paper like quality, suitable for counter bags, carrier bags and wrapping films, excellent processing.
AM 9450 F1 (EX5 HS)0.240.95For blown films with paper like quality, suitable for counter bags, carrier bags and wrapping films, excellent processing and sealability.
AM 9455 F (EX4)0.280.956For blown films with paper like quality, suitable for counter bags, carrier bags and wrapping films, excellent processing stiffer than HM 9450 F.
AM 9455 F1 (EX4 HS)0.240.957For blown films with paper like quality, suitable for counter bags, carrier bags and wrapping films, excellent processing, stiffer than HM9450 F1.
AM 9445 HT (EX6 HT)0.180.944For blown films with paper like quality, suitable for counter bags, carrier bags and wrapping film, excellent processing with high tenacity.

Download PDF


Extrusion – Filment (Basell license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
AF 7750 M2 (EX2 S)3.30.956Monofilament for fishing notes, geo textiles and civil engineering.

Download PDF

 Extrusion – Filment (Innovene license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
HD 5710 AA0.90.957Ropes, nets, knitted sacks, woven fabrics.

Download PDF

Extrusion – Cable Insulation (Basell license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
AF 7450 K (EX 7C)3.50.946Wire and cable insulation

Download PDF

HDPE-Injection Molding (Basell license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
AA  7260 (I1)520.957Light weight household and disposable articles
AB 6450 (I2)280.95Household articles less hard and less rigid than I1
AC  7260 (I3)230.957Transport and stacking crates, particular bottle crates
AD 7255 (I4)110.954Tick walled, highly stressed transport containers, e.g. refuse bin and fish crates, screw caps and cable clips.

Download PDF

HDPE-Injection Molding (Innovene license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
HD 5120 EA2.30.95Heavy duty and High ESCR application.
HD 5740 UA40.955UV resistance for thick components such as large refuse bins and pallets, boxes and dust bins.
HD 5050 EA4.50.95Heavy duty, High ESCR applications such as screw stopper. Caps & closures.
HD 5050 UA4.50.95Large dust bins & pails. Pallet boxes. Products with high ESCR and UV resistance.
HD 6070 EA70.958General purpose grade for rigid items such as fish boxes, Crates and tote boxes.
HD 6070 UA70.958UV stabilized for rigid items such as fish boxes, Crates and toys.
HD 5211 EA110.949Thin component, such as houseware and toys
HD 5211 UA110.949UV stabilized for thin component, such as houseware and toys
HD 5813 EA130.954Components requiring high rigidity, houseware and crates.
HD 5813 UA130.954UV stabilized for components requiring high rigidity, houseware and crates.
HD 5218 EA180.952Thin components such as food container, houseware and toys.
HD 5620 EA200.956General purpose.
HD 5226 EA260.953Thin wall injection application, housewares, caps and closures.
HD 5150 EA550.958High flow applications, Houseware, Food packaging.

Download PDF

C4 – LLDPE-Blown Film (Innovene license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
LL 0205 AF0.50.92Produce bag, medium duty sacks, refuse sacks, agricultural film.
LL 0205 HF0.50.92Liner bag, medium duty sacks, refuse sacks, agricultural film.
LL 0209 AF0.90.92Sealing layer, lamination, carrier and industrial bags.
LL 0209 AA0.90.92Liner bags, builders reel, Co-extrusion, shrink silage, green house and mulch film.
LL 0209 KJ0.90.92Liner bags, deep freeze film, garment wrap, refuse and heavy duty sacks.
LL 1209 AA0.90.92Lamination film.
LL 1209 KJ0.90.92Lamination film, display packaging, co-extrusion
LL 0410 AA10.925Thin film, shrink film. Blending component with PP.
LL 0410 KJ10.925Thin film, carrier bags, garment wrap.

Download PDF

C6 – LLDPE-Blown Film (Innovene license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
LL 6206 AF0.60.92Heavy duty sacks, agricultural film, mulch film
LL 6206 LJ0.60.921Mulch film, mailing film
LL 6209 KJ0.90.921carrier bags, mailing film, refuse bag
LL 6409 AA0.90.924Lamination, sealing layers in co-extrusion
LL 6409 KJ0.90.925Lamination, sealing layers in co-extrusion

Download PDF

C4 – LLDPE-Cast Film (Innovene license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
LL 0220 AA2.20.92Stretch wrap, Oriented Tape. Base resin for power cable compound insulation (low voltage), fiber optic jacketing.
LL 0640 AA40.93High quality cast films for display packaging, noncling layer for stretch film. Base resin for power cable compound insulation (low voltage), fiber optic jacketing.
LL 0640 KJ40.929High quality cast films such as display packaging, noncling layer for stretch film.

Download PDF

C4-MDPE- Rotational Molding (Innovene license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
HD 3840 UA40.938Tanks, containers and silos up to 30000 liters, technical parts, agricultural application.
HD 2840 UA40.928Tanks, containers and silos up to 30000 liters, technical parts, agricultural application.
HD 3560 UA60.935Tanks, containers and silos up to 30000 liters, technical parts, agricultural application.

Download PDF

LLDPE-Injection Molding (Innovene license)

Grade NameMFR(gr/10min) (5kg,190OC)DensityApplication
BD 24250 AA250.926Housewares, boxes and closures.
BD 30500 AA500.93Housewares, boxes and closures.

Download PDF

PP Homopolymer Fiber

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
F20S11Medium gas – fading resistance.BCF and CF multifilament, medium- low denier staple yarn, trilobe sections
F39S12General purpose with high gas – fading resistance.Wool staple fiber, heavy denier CF multifilament.
HP554N12Outstanding spin ability, superior thermo-bonded properties & excellent anti-gas fading propertiesFine denier staple fibers for nonwoven, thermo-bonded fabrics. Feminine care products, medical disposables and filters.
HP500N12Good processability & constant, high flow during extrusion.Wool staple fiber, heavy denier CF, multifilament for ropes, belts & straps and decorative ribbons.
V30S18Good flow, medium MWD.Fine denier staple fibers, thermo-bonded non-woven fabrics, upholstery and hygiene, Diapers, incontinence pads, feminine care.
HP554P18Good flow, Medium MWD, Anti gas fadingFine denier staple fibers, thermo-bonded non-woven fabrics, upholstery and hygiene, Diapers, incontinence pads, feminine care.
HP552R25High flow, medium MWD. High stretch ratio and gives tough and resilient fibers and Anti gas fading.Short & long spinning, low denier staple fiber, BCF and CF multifilament, low denier staple fibers for non-woven fabrics, medical-sanitary applications and wipes, carpet face yarns, backpacks, big bag handles and safety belts.
H30S35High flow, medium MWD.Fine denier cotton staple fiber, high speed short spinning operations. Coating of woven PP film yarn fabrics and paper coating. Injection molding for household articles, toys and packaging.

Download PDF

PP Homopolymer-Injection Molding

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
D50G0.3Excellent long – term heat ageing resistance, high mechanical properties.Injection molding of wheels, fittings and high performance items are other application.
Q30G0.7Particular molding purpose.Technical items such as cops & clothes- pins
HP502H1.8High stiffness and good impact strength, excellent processability.Appliance components, textile bobbins, wheels, fitting, closures, caps.
HP500J3.2High stiffness & fairly good impact strength with good processability.Technical items such as parts for small appliances & automotive industry. House wares, caps, closures, small containers, toys. It is also used for compounding
HP500L6Easy processing & high stiffness.Household articles, small containers, crates, garden furniture, stadium seats, toys, caps, closures. Components for appliances & automotive industry.
HP500M8Easy processing & high stiffness.Household articles, food containers, crates, garden furniture, toys, caps, closures. Components for appliances & automotive industry.
HP502N12Good flow, good dimensional stability & high stiffness.Consumer goods such as food containers,
vacuum flasks, flower pots, garden
furniture & small appliances. in the medical sector It can be used for 3-part syringes & a wide range of health care items.
HP500P16Good flow & easy mold filling & short cycle times and high stiffness.Thin-walled articles with long flow path such as containers, boxes, caps, closures. Polymer base for compounding & master batches.
Z11G25Suitable for medical gamma rays sterilization.Syringes and hospital articles
HP300R26Very good processability and high stiffness.Thin-walled containers & general purpose packaging items, vacuum flasks, kitchen articles. Compounding & master batches.
HP648S35High melt flow homo-polymer with a narrow molecular weight distribution and optimum antistatic properties.Thin-walled items such as video cassette boxes & small appliances.

Download PDF

PP-Homopolymer-Extrusion Thermoforming & Blow Molding

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
D60P0.3Excellent long- term heat ageing and detergents resistance. High mechanical propertiesPressure pipes, extruded and cast sheet.
HP501D0.7Excellent processability with an outstanding mechanical properties
balance.
Technical extrusion for strapping, sheet, profiles, nets and small diameter pipes such as refills for ball pens. Blow molding small and medium sized containers.
S60D1.8Excellent long- term heat stability with detergent resistance.Extruded sheet, blow molded technical items (such as tanks).
HP500H1.8Excellent process ability with high stiffness.Thermoforming such as drinking beakers, packaging for dairy products, nursery flower pots& trays for fruits, biscuits & chocolates. Film yarn, both with cast and tubular process, mono filaments, Strapping, extruded nets, blow molded small containers.
HP640H2Very high stiffness, excellent contact clarity, high gloss and good antistatic & excellent organoleptic properties.Hot fill applications and thermoforming vending cups, blister packs, pots for dairy products and trays for biscuits, chocolates, and fruits.
T31SE3.2High stiffness, excellent processability, good contact clarity and high gloss.Sheet for thermoforming. Vending cups, packaging for dairy products, trays for biscuits, chocolates and fruits. Co-extruded multilayer sheet with high barrier properties to produce retort containers.

Download PDF

PP-Homopolymer-Film Yarn and Monofilament

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
S30SW1.8Excellent processability with high stiffness, low water carry-overTextile Film yarn, ropes, extruded nets.
S33LS1.8High mechanical properties and medium UV resistance.Textile Film yarn, ropes, twins for agricultural use.
HP550J3.2Outstanding processability with good mechanical properties.Film yarn, both with cast & tubular processes for the production of carpet backings, bags, industrial fabrics, mats & artificial grass, baler twines, packaging twines & ropes. Monofilament used for instance for brush & broom filling. Extrusion of nets for various purposes. Stiff sheet for high quality thermoforming such as vending cups, packaging for dairy products & trays for fruit, biscuits & chocolates.
HP510L6Outstanding processability with good mechanical properties.Film yarn cast process for baler twins, packaging twins and ropes. Monofilament used in brush and broom filling and technical applications. Monolayer or co-extruded film for packaging. Thin sheet for stationary folders and sheets for thermoforming and extrusion of straws.

Download PDF

PP Homopolymer-Spun Bond

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
HP562R25Spun-bond grade with very narrow MWD and very high speed production.Low denier CF for spun bonding, non-woven fabrics, diapers, medical and sanitary tissues.
HOXP200435High fluidity spun-bond grade with very narrow MWD and anti-gas fading performance.Low denier CF for spun bonding, non-woven fabrics, diapers, medical and sanitary tissues. High output and high tenacity fibers.
HP565S38Very high flow spun bond grade with narrow MWD.Fine denier non-woven such as Non- woven fabrics for industrial and medical applications. Backing and lining for furniture and carpet industries.

Download PDF

PP-Homopolymer-Bioriented Film

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
S28F1.8Excellent processability and low water carry- over. High gloss
& transparency. Good optical properties.
Film for packaging, special grade for metallization. Monolayer and co extruded film. Also suitable for lamination to other flexible films.
S38F1.8High transparency and gloss. Very stable extrusion. Good mechanical properties.Monolayer films are used for food packaging, textiles packaging and flower wrappings, double bubble lines,
adhesive tapes. BOPP films are used for lamination to other flexible films.
S38FT1.8Excellent process- ability on tubular lines.Adhesive tapes. Packaging in general.
T36F2.5Excellent processability on cast lines, high transparency and gloss.Monolayer films are used for food packaging, textiles packaging and also for medical application.

Download PDF

PP-Random Copolymer-Injection Molding

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
EP2X83CI10Excellent clarity and gloss.Transparent house wares, food storage containers and packaging cosmetics and lids, caps and closures.
EP2YX29GA10Excellent flow and antistatic properties with very high transparency and gloss.Containers and thin-walled packaging with high clarity for food, cosmetics and pharmaceutical products. It also can replace PS whilst adding low weight, low odor transfer, chemical resistance and impact strength.
RP340R25High melt flow and outstanding transparency and gloss.Packaging for food and cosmetics, pharmaceutical products. Injection molded items for the medical sector such as syringes, test tubes and vials. Suitable for injection stretch blow molded containers and bottles.

Download PDF

PP Homopolymer-Cast Film

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
X30S9Good processability in cast process.Single layer and coextruded film for food packaging, textile wrapping, stationary and editorial application.

Download PDF

PP-Random Copolymer-Cast and Blown Film

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
RP210M6Good processability, excellent clarity and gloss and very good heat weld ability.Lamination to PP-film or other materials such as PA, polyester or aluminum. Packaging of foodstuffs and books, stationery, shirts and hosiery.
RP310M8Excellent processability, high clarity and gloss and good heat weld. Without slip or antiblock agents.Lamination to BOPP film or other materials. Packaging of foodstuffs and books, stationery, shirts and hosiery. Injection molding caps and closures
RP316M8Formulated with slip and antiblock and exhibits excellent antistatic. Excellent process ability, high clarity and gloss and good heat weld ability.Quality packaging as monolayer film or as welding layer on co-extruded structures. Lamination to BOPP film or other materials. Packaging of foodstuffs, books, stationery, shirts and hosiery.

Download PDF

PP-Random Copolymer-Bioriented Film

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
EP2S34F1.8Excellent processability on tubular lines, slip agent modifiedPackaging of bread and other foodstuffs
with heat-shrinkable film
RP129K5Low sealing temperature and, slip agent modified. Very high transparency, excellent gloss and outstanding heat weld ability.Suited for metallized BOPP films include packaging for foodstuffs and confectionary and medical applications drinks labels and liquor cartons.
EP3X37F8Low sealing temperature, slip and anti-blocking modified with very high transparency, excellent gloss and outstanding heat weld ability and show good hot tack.Quality packaging for food, stationery, cosmetics, clothes and cigarettes. Suitable for the production of shrinkable co-extruded BOPP film for display packaging of foodstuff products.

Download PDF

PP-High Impact Copolymer-Extrusion

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
EPD60R0.35Superior toughness even at low temperatures. Very high impact strength, extra heat stability and detergent resistance.Blow molding for appliance components, wheels, under the hood automotive parts, toolboxes, suitcases and large containers. Profiles, sewage pipes and tough sheet for industrial applications. Thermoforming trays for cold storage.
EP310D0.8Smooth process ability and high mechanical properties. Good stiffness and very high impact strength, even at -20°C.Film for adhesive tapes and lamination to paper and other resins. Extrusion blow molded containers for detergents, toiletries and foodstuffs. Corrugated board, smooth and corrugated pipe and sheet for thermoforming. Injection molding items with very good mechanical properties balance.
EPYS30RE1.3Smooth process ability, good stiffness and outstanding impact resistance, even at -20°C.Corrugated board and sheet for thermoforming. Blow molded bottles and containers for detergents and foodstuffs and technical parts for the automotive and appliance industries.

Download PDF

PP-Random Copolymer-Extrusion

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
ARP2300.2High heat and extremely high extraction stability.Sanitary pipes for cold & hot water, industrial and chemical pipes. Other applications are pipe fittings and profiles.
EP2X83CE1.8Excellent clarity and gloss.Bottle for detergents and toiletries, flat mineral water, jars for condiments and preserves.
RP210G1.8High cracking and chemical resistance.Film for packaging & sheet for stationery folders and displays. Extrusion blow molding of high gloss monolayer bottles, packaging of cosmetics, detergents, chemicals and food-stuffs.
RP240G1.8Low flow with a conventional MWD and is specially formulated with an additive package that enhances clarity.Blow-molded articles, extruded sheet and profiles with good melt strength, excellent clarity, excellent gloss and good regrind stability.
RP270G1.8High transparency and gloss, excellent processability & can be converted on form-fill-seal equipment.Blow molded medical articles. transparent bottles & containers for blood, intravenous solutions, pharmaceutical solutions, medicines & salves. Packaging for health care products. Film & sheet for thermoforming.

Download PDF

PP-High Impact Copolymer-Injection

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
EPS30R1.5High impact strength, excellent processing characteristics.Crates, paint fails, heavy duty packaging.
EP200K3.5Outstanding processability with extremely high impact resistance and very high toughness.Furniture and suitcases, sport and bicycle parts. Boxes, containers, pallets, crates, pails and lids. Bitumen modification and compounding applications.
EP300K3.5Medium – high flow, excellent balance between flow, very high impact strength and good stiffness.Medium sized containers, buckets, pails, crates for cold storage. Household articles. Small appliance, automotive and industrial application. Seats, chair shells, toys, suitcases. Thermoforming multilayer container for dairy products.
EP540L6Excellent balance of stiffness, impact strength (even at low temperatures) and process ability.Crates, caps and thin-walled packaging for cold shelf presentation. Automotive & Appliance parts, wheels, furniture, chair shells and stadium seats. Cast film for stationery.
EPC40R7Excellent balance of mechanical properties & process ability & features an excellent long-term heat stability. Very high resistance to chemicals & crazing.Automotive components such as battery cases, brake fluid reservoirs, wash water reservoirs, dashboard supports, luggage compartment trims & door trim panels.
EP440N12Improved mechanical property balance and outstanding stiffness.
Combines superior stiffness with high impact strength, even at low temperatures.
Packaging, automotive and consumer goods industries such as luggage, paint pails, buckets, crates, batteries and large toys.

Download PDF

PP-High Impact Copolymer-Injection

Grade NameMFR(gr/10min) (5kg,190OC)PropertiesApplication
EP548R21High stiffness, good impact resistance, high dimensional stability and excellent antistatic properties.Thin-walled or long flow path articles such as flower pots, filters, filters housings and appliance components.
EP740R25High stiffness, good impact resistance, high dimensional stability and excellent antistatic properties.Thin-walled or long flow path articles such as flower pots, filters, filters housings and appliance components.
EPH31RA40High stiffness, good impact resistance, outstanding organoleptic properties and excellent antistatic properties.Thin-walled packaging such as margarine tubs and pots for mayonnaise and dairy or fatty products. Caps, closures and flower pots, appliance components, and cool boxes.
EP548S45Nucleated with anti-static agent. Outstanding balance of mechanical properties and high fluidity.Extensively used in house wares and in thin-walled containers for food packaging (e.g. margarine tubs, yoghurt pots, etc.).
EP348U70Very high melt flow rate. Excellent impact resistance, even at low temperatures and effective antistatic. Low shrinkage and minimal warpage.Packaging for margarine tubs, pots for dairy products, ice-cream containers, trays, video cassette envelopes, caps and closures, Lunch-boxes, cool boxes, laundry baskets, and flower pots.
EP648V100Ultra-high fluidity. Good stiffness/ impact balance, good dimensional stability and outstanding antistatic properties.Packaging, house wares and garden furniture. Items with long flow paths such as laundry bins, drawer trays, video boxes, margarine tubs and packaging for dairy products.
