DRILLING   FLUIDS  PRODUCT  DATA

PAC  H.V.

Download PDF

Product Description:

     PAC H.V is high molecular weight poly anionic cellulose, provides

     filtration control and supplementary viscosity. It could be used in

     fresh water to salt saturated waters.

Application:



  • Filtration control.

  • Retard shale swelling.



Typical Physical Properties:



MUD  COMPOSITION

COMPOSITION

1

2

3

FW                                                  ML

350

–

259

S.S.W                                              ML

–

350

–

PAC HV                                         GR

4

4

4

CaCl2  (POW)                                GR

–

–

202

LIME  (SOL)                              DROP

Few

Few

Few

pH

9-9.5

9-9.5

9-9.5

MW                                                PCF

62.4

75

82+













































TEST RESULTS AFTER ROLLING AT 250 °F FOR 4 HRS.

 READING RHEOLOGY AT 140 °F

RESULTS

REQ

REQ

REQ

APP. VIS                                    CPS

50

50

70

Y.P                                     LBS/100FT2

40

30

35

GEL S.   10 Sec/10 min    LBS/100FT2

3/5

3/4

3/5

pH

8.6

9

7.4

API. W.L                                    ML

25

15

7

SETTLING

NIL

NIL

NIL











































PAC  H.V.  Continue:

Recommended Treatment:



    0.5 – 3 lb/bbl.



Source:



    KPA



Packaging:



     25 Kg kraft bags with PE liner, palletized and shrink-wrapped.

     Marked on: Name of manufacturer, Batch No. and Production date.



Safety Handling:



  • Non – toxic.

  • Keep in dry and sheltered place.
